Name: PSAP_Boundary

Display Field: DSPLAYNAME

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: Clay County NG9-1-1 PSAP SchemaElement #Descriptive NameField NameData TypeField WidthExample / Default DataDescriptionClay 1Public Safety Answering PointPSAPText50Red River Regional Dispatch CenterAgency that answers emergency calls.State 1Discrepancy Agency IDDISCRPAGIDText75Clay County GISAgency that receives a Discrepancy Report (DR), should a discrepancy be discovered, and will take responsibility for ensuring discrepancy resolution. This may or may not be the same as the 9-1-1 Authority. State 2Date UpdatedDATEUPDATEDateDefaultThe date and time that the record was created or last modified. This value MUST be populated upon modifications to attributes, geometry, or both.State 3Effective DateEFFECTIVEDateDefault1/1/2000The date and time that the record is scheduled to take effect.State 4Expiration DateEXPIREDateDefaultThe date and time when the information in the record is no longer considered valid.State 5Emergency Service Boundary Globally Unique IDES_NGUIDText254ESNXX@GIS.ClayCountyMN.govThe Globally Unique ID for each Emergency Service Boundary. The Emergency Service Boundary Globally Unique ID should start with the type of emergency service (e.g. EMS, LAW, FIRE, PSAP). XX=ObjectIDState 6StateSTATEText2MNThe name of a state or state equivalent, represented by the two-letter abbreviation given in USPS Publication 28 [15], Appendix B.State 7Agency IDAGENCY_IDText100GIS.ClayCountyMN.govA Domain Name System (DNS) domain name which is used to uniquely identify an agency. MUST be a registered DNS domain name.State 8Service Uniform Resource IdentifierSERVICEURIText254701-451-7660URI for call routing. This attribute is contained in the Emergency Service Boundary layer and will define the Service URI of the service. The URI is usually a Session Initiation Protocol (e.g. SIP or SIPs) URI but MAY be a telephone number (e.g. tel) URI that defines the route to reach the service.State 9Service Uniform Resource NameSERVICEURNText50nena:service:responder.emsThe URN used to select the service for which a route is desired. The ECRF is queried with a location and a service URN that returns the Service URI. Service=Law, Fire, EMS, State 10Service NumberSERVICENUMText15911The numbers that would be dialed on a 12-digit keypad to reach the emergency service appropriate for the location. Within the United States the Service Number for most emergencyservices is 9-1-1.State 11Agency vCard URIAVCARD_URIText254https://vcard.GIS.ClayCountyMN.gov/SheriffA vCard is a file format standard for electronic business cards. The Agency vCard URI is the internet address of an eXtensible Markup Language (XML) data structure which contains contact information (Name of Agency, Contact phone numbers, etc.) in the form of a vCard.State 12Display NameDSPLAYNAMEText60Clay SheriffA description or "name" of the service provider that offers services within the area of an Emergency Service Boundary.Clay 2Square MilesSQUARE_MILESDouble12,2Square Miles in Service Area calculated from Shape AreaClay 3County CodeCO_CODEText527027The combination of the two-character state numeric code and the three-character county code. Clay 4County NameCO_NAMEText40ClayThe name of the county.Clay 5PSAP CodePSAP_CODEText5RRRDCThe 4 to 5-character Public Safety Answering Point identifier code.

Service Item Id: 7d333a09927a4a708ebe972db3f856e2

Copyright Text: Clay County GIS

Default Visibility: true

MaxRecordCount: 2000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -96.84031644244344
YMin: 46.62745994980587
XMax: -96.16419300246247
YMax: 47.15234562399732
Spatial Reference: 4326  (4326)  VCSWkid(105703)  LatestVCSWkid(6360)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [242, 252, 204, 255]
Outline:
Style: esriSLSSolid
Color: [110, 110, 110, 255]
Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• PSAP ( type: esriFieldTypeString, alias: Public Safety Answering Point, length: 50 )
• DISCRPAGID ( type: esriFieldTypeString, alias: Discrepancy Agency ID, length: 75 )
• DATEUPDATE ( type: esriFieldTypeDate, alias: Date Updated, length: 8 )
• EFFECTIVE ( type: esriFieldTypeDate, alias: Effective Date, length: 8 )
• EXPIRE ( type: esriFieldTypeDate, alias: Expiration Date, length: 8 )
• ES_NGUID ( type: esriFieldTypeString, alias: Emergency Service Boundary NENA Globally Unique ID, length: 254 )
• STATE ( type: esriFieldTypeString, alias: State, length: 2 )
• AGENCY_ID ( type: esriFieldTypeString, alias: Agency ID, length: 100 )
• SERVICEURI ( type: esriFieldTypeString, alias: Service URI, length: 254 )
• SERVICEURN ( type: esriFieldTypeString, alias: Service URN, length: 50 )
• SERVICENUM ( type: esriFieldTypeString, alias: Service Number, length: 15 )
• AVCARD_URI ( type: esriFieldTypeString, alias: Agency vCard URI, length: 254 )
• DSPLAYNAME ( type: esriFieldTypeString, alias: Display Name, length: 60 )
• SQUARE_MILES ( type: esriFieldTypeDouble, alias: Square Miles )
• CO_CODE ( type: esriFieldTypeString, alias: County Code, length: 5 )
• CO_NAME ( type: esriFieldTypeString, alias: County Name, length: 40 )
• PSAP_CODE ( type: esriFieldTypeString, alias: PSAP Code, length: 5 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape.STArea() ( type: esriFieldTypeDouble, alias: Shape.STArea() )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
